501TC

글  쓴  이
 박만종

조  회  수

    2176
작  성  일
 2003-03-20 오후 5:55:48   E-mail  mjtech@unitel.co.kr


다음과 같이 참조하십시요
Hello Dear;

After looking at the manual in more detail. Is best to write you
the
information as to how to change from one range to the other.

The output range is determined by the strapping of terminal strip
TB2.
TB2 is located on the rear of the 751TC power source. This is the
same for 501TC, 751TC, and 1001TC.

Low or high range AC output. TB2 jumpers:

Low range: 0-130 volts.
Connect terminals 2, 3 and 4. Terminal 3 is the output high.
Connect terminals: 5 and 6. Terminal 6 is the output low.

High range: 0-260 volts.
Connect terminals 1 and 3. Terminal 3 is the output high.
Connect terminals: 4 and 5. Terminal 6 is the output low.




>안녕하십니까 ?
>
>오전에 H/P통화로 간단히 문의 드렸던 건으로
>저희가 가지고 있는 장비 매뉴얼을 구할수 있을까
>하여 요청 드립니다.
>
>장비명은 AC POWER SOURCE 751TC (CALIFORNIA INSTRUMENRS製)
>OPERATING 매뉴얼이 필요합니다.
>귀사 보유중인 501TC 장비와 유사하다고 알고 있는데
>혹시 가능하시면 COPY 가능 한지요.전면 COTROLLER는
>848TCP 입니다.
>
>장비 뒤쪽 Terminal 연결방법 및 848TCM OPERATING MANUAL
>입니다.
>
>구미 세아씨스텍
>TEL:054-451-5973
>FAX:054-451-5974
>
>P.S:필요한 실비는 저희가 송금하겠습니다.
